Compressor type I
tot
(1) Max
fuse (1)
I
tot
(2) Max
fuse (2)
Q21/Q2
2/Q23/
Q24
Q15
SF 17
+
UL/cUL 60 Hz 460 V 33 A 40 A 37 A 45 A 12.0 A 0.43 A
SF 17
+
UL/cUL 60 Hz 575 V 27 A 30 A 30 A 35 A 9.6 A 0.44 A
Compressor type I
tot
(1) Max
fuse (1)
I
tot
(2) Max
fuse (2)
Q21/Q2
2/Q23/
Q24
Q15
SF 22
+
IEC 50 Hz 230 V 85 A 100A 90 A 125 A 23.3 A 0.38 A
SF 22
+
IEC 60 Hz 380 V 53 A 63 A 57 A 63 A 14.5 A 0.26 A
SF 22
+
IEC 50 Hz 400 V 49 A 63 A 52 A 63 A 13.4 A 0.22 A
SF 22
+
IEC 50 Hz 400 V + N 49 A 63 A 58 A 63 A 13.4 A 0.22 A
SF 22
+
UL/cUL 60 Hz 200 V 101 A 125 A 109 A 125 A 25.0 A 0.74 A
SF 22
+
UL/cUL 60 Hz 230 V 88 A 110 A 94 A 125 A 24.0 A 0.26 A
SF 22
+
UL/cUL 60 Hz 460 V 44 A 60 A 48 A 60 A 12.0 A 0.43 A
SF 22
+
UL/cUL 60 Hz 575 V 35 A 40 A 38 A 40 A 9.6 A 0.44 A
Compressor type I
tot
(1) Max
fuse (1)
Q21/Q2
2
SFD 11
+
IEC 50 Hz 230 V 21 A 25 A 22.3 A
SFD 11
+
IEC 60 Hz 380 V 14 A 16 A 14.5 A
SFD 11
+
IEC 50 Hz 400 V 12 A 16 A 12.8 A
SFD 11
+
UL/cUL 60 Hz 200 V 26 A 30 A 21.9 A
SFD 11
+
UL/cUL 60 Hz 230 V 22 A 30 A 19.0 A
SFD 11
+
UL/cUL 60 Hz 460 V 11 A 15 A 9.5 A
SFD 11
+
UL/cUL 60 Hz 575 V 9 A 15 A 7.6 A
Compressor type I
tot
(1) Max
fuse (1)
Q21/Q2
2
SFD 15
+
IEC 50 Hz 230 V 28 A 32 A 15.0 A
SFD 15
+
IEC 60 Hz 380 V 17 A 20 A 8.9 A
SFD 15
+
IEC 50 Hz 400 V 16 A 20 A 8.7 A
SFD 15
+
UL/cUL 60 Hz 200 V 31 A 35A 13.7 A
SFD 15
+
UL/cUL 60 Hz 230 V 28 A 35 A 12.6 A
SFD 15
+
UL/cUL 60 Hz 460 V 14 A 20 A 6.3 A
SFD 15
+
UL/cUL 60 Hz 575 V 11 A 15 A 4.9 A
Compressor type I
tot
(1) Max
fuse (1)
Q21/Q2
2
SFD 22
+
IEC 50 Hz 230 V 41 A 50 A 22.3 A
