2.4 Electrical system
Cubicle layout
Electrical cabinet SF 15
+
, SF 17
+
and SF 22
+
, typical
Electrical cabinet SFD 11
+
, SFD 15
+
and SFD 22
+
, typical
K21, K22,... Contactor 1X0, 4X3,... Terminals
Q21,Q22,... Circuit breaker T1, T4,... Transformer
F1,F2,... Fuses
