SRTT-B User Guide
ACCESSORIES
A series of mechanical joint simulator to be used with the SRTT-B is available:
Model Drive
Rated Capacity
Nm
Ordering No.
TJ SRTT-B S – 0.5
½” square
0,5
8059 0940 01
TJ SRTT-B H – 0.5
½” square
0,5 8059 0940 02
TJ SRTT-B S – 2
½” square
2 8059 0940 03
TJ SRTT-B H – 2
½” square
2 8059 0940 04
TJ SRTT-B S – 5
½” square
5 8059 0940 05
TJ SRTT-B H – 5
½” square
5 8059 0940 06
TJ SRTT-B S – 25 36 mm Hex 25 8059 0940 07
TJ SRTT-B H – 25 36 mm Hex 25 8059 0940 08
TJ SRTT-B S – 50 36 mm Hex 50 8059 0940 09
TJ SRTT-B H – 50 36 mm Hex 50 8059 0940 10
TJ SRTT-B S – 100 36 mm Hex 100 8059 0940 11
TJ SRTT-B H – 100 36 mm Hex 100 8059 0940 12
TJ SRTT-B S – 250 36 mm Hex 250 8059 0940 13
TJ SRTT-B H – 250 36 mm Hex 250 8059 0940 14
TJ SRTT-B S – 500 50 mm Hex 500 8059 0940 15
TJ SRTT-B H – 500 50 mm Hex 500 8059 0940 16
TJ SRTT-B 1000 50 mm Hex 1000 8059 0940 17
Adapters:
Model
Ordering No.
QAT Accessory adapter SRTT-B 25 to 250 for ⅜” 8059 0978 65
QAT Accessory adapter SRTT-B 25 to 250 for ½” 8059 0978 66
QAT Accessory adapter SRTT-B 500 to 2000 for ½” 8059 0978 67
QAT Accessory adapter SRTT-B 500 to 2000 for ¾” 8059 0978 68
QAT Accessory adapter SRTT-B 500 to 2000 for ½” 8059 0978 69
9836 5232 01 Edition 2.0 5 (8)
