- 41 -
After warming up the machine is ready to be loaded
and is waiting for a load command; the display shows
Press the load button, the display will show
When the load button is pressed and the measured
vessel pressure is lower then 4.5 bar, the controller
will run a specific program to reach the requested
4.5 bar, in order to be able to load the machine.
The engine will now run at maximum rpm, the display
will show
The loading valve will be energized and pressure
starts building up.
Active Buttons
MAIN VIEW
READY TO LOAD
3.6
1200RPM 3.6bar1286h
40%
Active Buttons
MAIN VIEW
BUILDING UP VESSEL PRESSURE
3.9
1200RPM 3.9bar1286h
40%
Active Buttons
MAIN VIEW
PREPARING TO LOAD
4.7
1800RPM 4.7bar1286h
40%
To Next Page
