- 106 -

AXLE - OPTIONS

- 1092 0499 94 AXLE (From page 103)

5 1092 0499 26 AXLE BODY 1

10 1092 0499 27 INNER TUBE 2

15 1092 0572 44 INNER TUBE SUPPORT 4

20 1092 0499 38 SPRING SUPPORT 1

25 1092 0572 16 BRAKE 2

30 1092 0572 26 RING SUPPORT 2

35 1092 0572 27 RING 2

40 1092 0572 33 BEARING 2

45 1092 0572 34 BEARING 2

50 1092 0572 11 HUB 2

55 0333 2230 00 SPRING WASHER 12

60 0147 1361 03 SCREW 12

65 1092 0572 15 BRAKE HUB 2

70 0162 1567 30 SCREW 4

75 1092 0572 24 WHEEL BOLT 6

80 0333 2145 00 WASHER 12

85 0261 1099 32 NUT 12

90 1092 0572 23 WHEEL NUT 6

95 1092 0572 10 WHEEL BOLT 6

100 0299 1000 07 WHEEL NUT 6

105 1092 0499 37 TORSION SPRING 4

110 1092 0572 42 RING 2

115 1092 0572 19 SET SCREW 2

120 0261 1099 35 NUT 2

125 1092 0499 23 REAR CABLE 2

130 1092 0499 24 CONNECTION PLATE 1

135 0544 1106 00 GREASE NIPPLE 4

140 1092 0572 13 NUT 2

145 0111 1314 00 SPLIT COTTER PIN 2

150 1092 0572 12 CAP 2

155 0113 4189 00 PIN 1

160 0301 2358 00 PLAIN WASHER 1

165 0111 1254 00 SPLIT COTTER PIN 1

REF PART NUMBER DESIGNATION QTY REF PART NUMBER DESIGNATION QTY REF PART NUMBER DESIGNATION QTY

1092 0499 94/00
