100, 200, 500, 700, & FMA Series
Floor-Standing Cabinets
1601 JACK MCKAY BLVD.
ENNIS, TEXAS 75119 U.S.A.
d. If equipment requires rear rack rails, additional rail pairs may be purchased (excluding 100 Series cabinets). In general, any piece of gear
heavier than 25 lbs. per rack unit should utilize a rear rack rail. Consult chart below:
e. If any type of pullout device, like a drawer or monitor, is installed in the cabinet, be sure the cabinet is firmly attached to the floor before
opening pullout.
f. After completing the equipment installation, be sure all doors (if any) close properly.
15. Cabinet Accessories
Hardware - Convenient packages of 10-32 rack screws with captive washers.
Rear Rack Rails - A “must have” accessory for fully-supporting heavy loads within a cabinet.
Shelf Systems - Useful whenever equipment does not include provisions for rack-mounting. Heavier equipment may require Rear Rack Rails (listed
above) and Shelf Rear Support Brackets. Equipment may be held in place using Equipment Clamping Kit.
Rack Units Front Rail Max Use Front + Rear Rail Max
1 RU 25 lbs 56 lbs
2 RU 50 lbs 112 lbs
3 RU 75 lbs 168 lbs
4 RU 100 lbs 224 lbs
n RU n x 25 lbs n x 56 lbs
200, 500 and 700 Series Cabinets
RR21 RAIL PR 21RU 36IN BLK
RR24 RAIL PR 24RU 42IN BLK
RR35 RAIL PR 35RU 61IN BLK
RR40 RAIL PR 40RU 70IN BLK
RR44 RAIL PR 44RU 77IN BLK
Shelf (10" Deep) - Cannot use Rear Support Bracket or Clamping Kit
SH1-10 SHF VNT 1RU 10D #052
Equipment Clamping Kit
SHCK SHF CLP KIT SH15/SH22 SER #052
Shelf (15" Deep)
SH2-15 SHF VNT 2RU 15.5D #052
SH3-15 SHF VNT 3RU 15.5D #052
SH4-15 SHF VNT 4RU 15.5D #052
Shelf (22" Deep)
SH2-22 SHF VNT 2RU 22D #052
SH3-22 SHF VNT 3RU 22D #052
SH4-22 SHF VNT 4RU 22D #052
Shelf Rear Support Brackets
SHRSB2 SHF BRKT RR SPT 2RU SH15/SH22 #052
SHRSB3 SHF BRKT RR SPT 3RU SH15/SH22 #052
SHRSB4 SHF BRKT RR SPT 4RU SH15/SH22 #052
FMA Series Cabinets
FMA-RRK35 RAIL PR 35RU 61IN FMA BLK
FMA-RRK44 RAIL PR 44RU 77H FMA BLK
RSCW100 HDWR 10-32 X
3
⁄4" 100/BAG PHIL SCR/CAP WSH BLK
RSCW500 HDWR 10-32 X
3
⁄4" 500/BOX PHIL SCR/CAP WSH BLK
HK-40 HDWR 10-32 X 1" 40 PHIL SCR/WSH CHR
Writing Surface
WS2-12 FRONT RACK MOUNT 2RU 12" DEEP
Compact Disc Storage Shelf - Holds 40 CDs
CD4 CD STORAGE SHELF 3RU
Front & Rear Rail Sliding Shelf/Tray
VTD1-16 SLIDING SHELF/TRAY 1RU W/16"
