EXPLODE NO. DESCRIPTION ATLAS P/N QTY.
1 Air Inlet SPN-00001 1
2 Exhaust diffuser SPN-00002 1
3 Handle Assembly SPN-00003 1
4 Roll Pin ø3 X 28 (MM) SPN-00004 1
5 Trigger SPN-00005 1
6A Gasket SPN-00040 1
6 Ball Bearing (696z) SPN-0006 1
7 Rear End Plate SPN-0007 1
8 Rotor 67 SPN-0008 1
8A Sun Gear (12T) SPN-00029 1
9 Rotor Blade SPN-0009 5
10 Roll Pin ø 2.5 X 10 (MM) SPN-00010 2
11 Cylinder SPN-00011 1
12 Front End Plate ø 34 X 6 (MM) SPN-00013 1
13 Ball Bearing (626z) SPN-00015 1
14 Washer SPN-00016 1
15 Planet Gear (15T) – (801 only) SPN-00017 3
15 Planet Gear (18T) – (802 only) SPN-00026 3
16 Planet Pin (801 only) SPN-00027 1
16 Planet Pin (802 only) SPN-00018 1
17 Internal Gear SPN-00044 1
18 Drive Spindle SPN-00020 1
18A Retaining Ring SPN-00019 1
19 Ball Bearing (6200z) SPN-00046 2
20 Nose Housing SPN-00021 1
21 Locking Balls SPN-00022 2
22 Change Value Spring SPN-00023 1
23 Quick Change Sleeve SPN-00024 1
25 Circlip SPN-00025 1
A Hex Driver See Chart Below 1
B Screw Mandrel See Chart Below 1
C Bearings Assy. See Chart Below 1
D Anvil See Chart Below 1
MODEL 801 / 802
Complete
Thread Size Nose Piece A B C D
Assembly
4-40 AENP-440 AEHD-4 AESH-440-150 AEPB-4 ANSS-4
6-32 AENP-632 AEHD-6 AESH-632-150 AEPB-6 ANSS-6
8-32 AENP-832 AEHD-8 AESH-832-150 AEPB-8 ANSS-8
10-24 AENP-1024 AEHD-10 AESH-1024-150 AEPB-10 ANSS-10
10-32 AENP-1032 AEHD-10 AESH-1032-150 AEPB-10 ANSS-10
M3 AENP-M3 AEHD-M3 AESH-M3-35 AEPB-M3 ANSS-M3
M4 AENP-M4 AEHD-M4 AESH-M4-35 AEPB-M4 ANSS-M4
M5 AENP-M5 AEHD-M5 AESH-M5-45 AEPB-M5 ANSS-M5
