Quick Start Steps 4
Cyclops
Charge The Batteries
Remove the Control Unit from the platform, remove the power cord normally
placed in the printer compartment, connect the cable to the Control Unit and to
a suitable power outlet.
Leave the power switch of the Control
Unit in OFF position. Only the charger is
energized at this time.
Identify the box containing the measuring
heads and open it.
Remove the batteries inserted in the heads (push the 2 tabs on each side) and
put them in charge - The 2 red LEDs on the charger will light up.
Checking And Adjusting The Lift
With the lift all the way down, hanged on
the supports, check and adjust the ramps.
Any registration made on a vehicle is done
properly if the vehicle is on level then
the lift should be “leveled”. The 3D wheel
aligner compensates the lift variation
between no load condition and to different
loads as per lift variation between the
ground position and the different heights
to working position (ramps at different heights) but to do this, it is has to start
from a known condition: LIFT LEVELED AT THE GROUND POSITION ! !
