Atlona AT-HDRP User Manual

3
SPECIFICATIONS
Model Name
AT-HD50SS
AT-HD50RSL
Technical
Role of usage
Sender (TX)
Sender / Receiver (TRX)
HDMI compliance
HDMI 1.3c
HDCP compliance
Yes
Video bandwidth
Single-link 225MHz (6.75Gbps)
Video support
480i / 480p / 720p / 1080i / 1080p60 24/30/36-bit color
HDMI transmission
(24-bit)
Full HD (1080p)  40m (130ft) [CAT5e] / 50m (165ft) [CAT6]
HD (720p/1080i)  50m (165ft) [CAT5e] / 60m (200ft) [CAT6]
Audio support
Surround sound (up to 7.1ch) or stereo digital audio
Equalization
None
8-level digital control
Input TMDS signal
1.2 Volts (peak-to-peak)
Input DDC signal
5 Volts (peak-to-peak, TTL)
ESD protection
[1] Human body — ±19kV (air-gap discharge) & ±12kV (contact discharge)
[2] Core chipset — ±8kV
PCB stack-up
4-layer board (impedance control — differential 100; single 50)
Input
1 x HDMI
1 x RJ-45
Output
1 x HDMI
1 x RJ45
1 x 3.5mm audio socket
1 x HDMI
1 x RJ-45
1 x 3.5mm audio socket
HDMI connector
Type A (19-pin female)
RJ45 connector
WE/SS 8P8C with 2 LED indicators
DIP switch
2-pin for EDID & audio/video setting
None
Rotary control switch
None
Signal equalization
Mechanical
Housing
Metal enclosure
Dimensions
[L x W x H]
Model
180 x 108 x 27mm (7" x 4.3" x 1.1")
Package
330 x 200 x 95mm (1’1" x 8" x 4")
Weight
Model
515g (1.1 lbs)
515g (1.1 lbs)
Package
970g (2.1 lbs)
970g (2.1 lbs)
Fixedness
Wall-mounting case with screws
Power supply
5V DC
Power consumption
1 Watt [max]
Operation temperature
0~40C (32~104F)
Storage temperature
-20~60C (-4~140F)
Relative humidity
20~90% RH (no condensation)
