ATS DWS-15 - Specifications

17
SPECIFICATIONS
MODEL # DWS-7 & SE-7 DWS-15 & SE-15 DWSW-8 DWSW-15
MAXIMUM
CAPACITY G.P.M.
7 15 8 15
SHIPPING WEIGHT 19 LBS 28 LBS 22 LBS 28 LBS
# OF LAMPS 1 1 1 1
KW @ 120V .038 .067 .038 .067
KW @ 220V .033 .064 .033 .064
AMPS @ 120V .32 .56 .32 .56
AMPS @ 220V .15 .29 .15 .29
INLET / OUTLET SIZE
¾'' STD. MNPT ¾'' STD. MNPT ¾'' STD. MNPT ¾'' STD. MNPT
TOTAL DIMENSION
INCL. WALL MOUNT
L X W X D
18'' X 4'' X 7''
36'' X 4'' X 7'' 24'' X 9'' X 6½'' 36'' X 4'' X 8''
DISINFECTION
CHAMBER MATERIAL
(WETTED PARTS)
304 SS TUBING 304 SS TUBING 304 SS TUBING 304 SS TUBING
CABINET HOUSING
MATERIAL
304 SS
#4 POLISH
304 SS
#4 POLISH
304 SS
#4 POLISH
304 SS
#4 POLISH
ATS-254M MONITOR N / A OPTIONAL OPTIONAL OPTIONAL
U.V. DOSAGE > 30,000
µw sec./cm
2
> 30,000
µw sec./cm
2
> 30,000
µw sec./cm
2
> 30,000
µw sec./cm
2
