DWS-15 Parts List
CODE PART# DESCRIPTION QTY.
1 ATS-5200 Chamber 1
2 ATS-5173 Site Port O-Ring 1
3 ATS-5172 Site Port Lens 1
4 ATS-5171 Site Port Nut 1
5 ATS8-544 End Nut O-Ring (seal quartz sleeve) 2
6 ATS5-411 Brass End Nut 2
7 ATS8-546 O-Ring (for shroud on end nut) 2
8 ATS-4010 Socket w/ Wire 2
9 ATS-N1156 Brass Shroud 2
10 ATS-7030 Grommet (for wire assy. in shroud) 2
11 ATS-R02 3/4” Flo.-Et. Retainer 12 - 15 gpm 1
12 ATS-F15 15 gpm Flo.-Et. 1
13 ATS-4000 Power Cord 1
14 ATS-6L1 Strain Relief (for Power Cord) 1
15 ATS1-421 Ballast 120V/60Hz 1
16 ATS8-246 Bulb 1
17 ATS6-608 Quartz Sleeve 1
18 ATS-6200 Cover w/o Hole for Plastic Lens 1
19 ATS-7600 Plastic Sight Lens (for cover) 1
KITS
ATS-4025 Kit: 5 thru 10
ATS-5177 Lens Kit: 2 thru 4
