DWSW-8 Parts List
CODE PART# DESCRIPTION QTY.
1 ATS-5227 Chamber 1
2 ATS-5173 Site Port O-Ring 1
3 ATS-5172 Site Port Lens 1
4 ATS-5171 Site Port Nut 1
5 ATS8-544 End Nut O-Ring (Seal Quartz Sleeve) 2
6 ATS5-411 Brass End Nut 2
7 ATS8-546 O-Ring (for shroud on end nut) 2
8 03-09-2022 Socket Housing 2
9 ATS-N1156 Brass Shroud 2
10 ATS-7030 Grommet (for wire assy. in shroud) 2
11 ATS-R01 ¾” Flo.-Et. Retainer 6-8 gpm 1
12 ATS-F08 8 gpm Flo.-Et. 1
13 ATS-4000 Power Cord 1
14 ATS-6L1 Strain Relief (for power cord) 1
15 ATS-7031 Grommet 2
16 ATS1-421 Ballast 1
17 ATS-1535 Outer Ring Gasket 1
18 ATS-0005 End Plate 1
19 ATS-2535 SS
5
/16 - 24 x
3
/4 Hex Bolt 6
20 02-09-1104 Socket Terminal 4
21 ATS-8540 Wiper Rod Assembly 1
22 ATS-3535 Wiper Rod Compression Fitting 1
23 ATS-7535 Wiper Rod Knob 1
24 ATS-6535 Wiper Rod Gasket 2
25 ATS1-483 Quartz Sleeve 1
26 ATS2-457 Bulb 1
27 ATS-6300 Cover 1
KITS
ATS-4025 Kit: 5 thru 10
ATS-5177 Lens Kit: 2 thru 4
