Recommended connection schemes
The scheme of connection with mixing system REGUMAT ATTACK-OVENTROP
17
ATTACK
BOILER
Expansion vessel
Pump
Regumat
ATTACK-
-OVENTROP
Heating system
12
43
Check valveCheck valve
