ATTACK PELLET Series - Dependency of output on potentiometer P2 settings

Dependency of output on potentiometer P2 settings
The diagram showes the dependency of boiler output on settings of potentiometer no.2
for pellets with diameter of 6 mm, which are in a compliance with the fuel
specification described in this manual, and for the pellet feeder leaning under the
angle of 45°.
16
Pot. 2 - blinking
