Technical data
WARNING
Voltage and energy consumption
The electrical installation must be carried out by a certified electrician. The mains cable
may only be exchanged by the electrician approved by us.
Component Mains/Volt Min./Max.
Load
Fuse
Display 5V DC 1 W ---------
Fan 230V~ 15-35W 800mA
Circuit board 230V~ ---------
Grate cleaning 24V DC 10-50W Switched
Ignition 230V~ 950-1100W 6.3A
External pellet
feeder
230V~ 15-220W 1A
Model Iwabo Villa S2
Fuel Wooden pellets, 6--
10 mm
Output range 10-20 kW
3 m
Weight 16 kg
Main voltage mains current Hz
~230V 10A fuse 50
5
For boilers with fire chambers up to
