OUTPUT SETTING
ENTER
> EXIT
MENU "ADVANCED"
O:18
N:23
IGN. SETTING
ENTER
< > EXIT
Advanced menu
The following items/parameters to be adjusted by qualified person only.
For increasing and decreasing the time or value
When accessing the Advanced menu
EXAMPLE:
ADJUSTMENT OF OUTPUT:
Adjustment of ignition:
All the items of Advanced menu can be accessed by pressing the "M" button. The current setting is
always displayed in the lower left corner after „O:“ (time/value), while the new value can be inserted
in the lower right corner after „N:” (time/value).
press the „+” and „-“ buttons. For confirming and
saving the new values press „M”. For escaping without saving press „E”.
add 5 to the random number displayed. For example, there
might be an „18“ both after „O:” and „N:”. Now push the „+” button until N:18 has become
„N:23”, then „M”. This gives you access to the menu. .
OldNew
Here you can choose the three outputs to be used for the OUTPUT MODES of the generally
accessible menu (10-20 kW).
When pressing the „M”button when „OUTPUT SETTING”is shown, "OUTPUT 1 (kW)“ will appear
in the upper left corner. In lower left corner „O:12” will be shown (i.e. the current kW output value).
For changing the output range, press „+” button until the desired new value is displayed in the lower
right corner, for instance „N:14”. If you now press „M”, this new value for output mode 1 will be
14kW. After this “Output 2” will be displayed and can be adjusted to the desired value. If nothing
should change, press „M”, which saves the value displayed, for example: „N:15”, so that output
mode 2 will be 15 kW.
If you want to leave the display without making any changes, press „E”.
Here you adjust the amount of ignition fuel in %, it has been automatically calculated based on the
weight entered in PELLETS TRIM.
When pressing the „M” button in this parameter, "Ignition dose 1" is displayed in the upper left
corner. Changes are made in %, the start dose beeing pre-set to 170g. If you increase the value to
110%, the start dose changes to 187g.
If the burner failed in its first ignition attempt, “Ignition dose 2” will be activated, which is
factory pre-set to 50% of 170g, i.e. 85g.
24
