ATTACK PELLET Series - Dimensions, Parts, and Installation; Dimensions of the boiler ATTACK PELLET; The main parts of ATTACK PELLET boiler

The main parts of ATTACK PELLET boiler
Dimensions of the boiler ATTACK PELLET
7
1 boiler body
2 casing
3 ash pan door
4 door of the inspectional opening
5 burner
6 pipe exchanger
7 turbulators
8 pull rod of turbulators
9 flue gas reciever with flue
10 rising pipe 1"
11 return pipe 1"
12 filling valve 1/2"
14 main switch
15 burner switch
16 boiler thermostat
17 thermomanometer
18 electrical fuse 10A
19 emergency thermostat
