ATV MOW - Page 18

17
ATV FLAIL MOWER ASSEMBLY
No.
Part No.
Name & Specifications
Qty
26
EF100.00.101
Sleeve
56
27
RK120.114A
Blade
28
28
GB5783-86
Blot M12x80
28
29
EF100.00.122
Baffle
12
30
EF100.00.121
Baffle
1
31
MFP120.00.109
Shaft
1
32
MFP120.00.024
Protecting Bracket
2
33
MFP120.00.116
Tension Spring
1
34
UC207-Z
Bearing Seat 90207
2
35
GB13871-94
Oil seal FB55x80x8
2
36
RK120.109
Oil-sealing Sleeve
2
37
GB1152-89
Oil Cup M8x1
1
38
MFP120.00.036
Bracket for Tension Spring
1
39
GB97.1-85
Plain Washer 10
1
40
GB6184-86
Locking Nut M10
1
41
GB5783-86
Blot M8x16
1
42
GB96-85
Plain Washer 8
1
43
MFP120.00.153
Tensioner
1
44
GB279-88
Bearing 180105
2
45
MFP120.00.154
Sleeve
1
46
GB893.1-86
Circlip 47
1
47
MFP120.00.101
Cover
2
48
GB5783-86
Blot M8x25
2
49
GB97.1-85
Plain Washer 8
2
50
GB6184-86
Locking Nut M20
2
