ATV FLAIL MOWER PART LIST
NO.
Part Code
Part Name
Qty
Note
1
ATH120.011
Cover Weldment
1
2
UC207
Bearing Set
2
3
ATH120.005
Blade Axle Assy
1
4
ATV120.106
Bush
1
5
GB/T 13871.1-2007
Seal Ring
1
B56
6
GB/T 95-2002
Flat Washer
28
24*13.5*2.5
7
GB/T93-1987
Spring
8
12
8
ATV120B.103
Slide Plate R
1
9
ATV120B.104
Slide Plate L
1
10
ATV120B.105
Buffer Axle
1
11
ATV120B-130
Adjust Plate R
1
12
UC205
Bearing Set
2
13
ATV120B.131
Adjust Plate L
1
14
ATV120B.013
Roller Weldment
1
15
ATV120B.106
Scrape Plate
1
16
ATV120.501
Adjust Rod Assy
1
17
GB/T 859-1987
Spring 8
2
8
18
GB/T 95-2002
Flat Washer
8
10
19
GB/T 889.2-2000
Locking Nut M10
1
M10
20
GB/T 95-2002
Flat Washer
2
22
21
GB/T 6182-2000
Locking Nut M202
2
M22
22
ATV120C.012
Cover Weldment
1
23
Hexagon Lock Nut
Locking Nut M10
3
24
GB/T 5781-2000
Bolt M10*30
3
M10×30
25
GB/T 889.1-2000
Locking Nut M12
16
M12
26
GB/T 5781-2000
Bolt M12*65
2
M12×65
