Chapter 1
Connections and connectors
CONNECTION STANDARDS
The in- and output connections for AUDAC audio equipment are performed
corresponding to international wiring standards for professional audio equipment.
XLR:
For balanced line output connections
Pin 1: Ground
Pin 2: Signal +
Pin 3: Signal -
ATTENTION
Make sure the power of the device and other connected devices is switched off, before
any connections or wiring adjustments are being made. Disregarding this rule can lead
to electrical shocks and/or permanent damage of the equipment.
