Note
Temperature of refrigerant circuit components should be equal
to ambient temperature. Pressure will deviate from values in
table if individual components of refrigerant circuit are warmer
or colder.
At absolute pressure, 0 bar corresponds to absolute vacuum.
Normal ambient pressure (positive pressure) corresponds to
1 bar absolute pressure. 0 pressure corresponds to an abso‐
lute pressure of one bar on most pressure gauges (indicated
by -1 bar below 0).
On vehicles with High pressure sensor -G65- or A/C pressure/
temperature sensor -G395- for which measured pressure is
displayed in measured value block, pressure measured
should coincide using Vehicle Diagnosis, Testing & Informa‐
tion System -VAS5051B- (“OBD“ or “Guided Fault Finding for
the A/C system“) and ⇒ Heating, Ventilation and Air Condi‐
tioning; Rep. Gr. 87 ; Diagnosis and Testing (vehicle-specific
repair manual).
Pressure is measured in different units: 1 MPa (mega Pascal)
corresponds to 10 bar positive pressure or 145 psi, 1 bar ab‐
solute pressure corresponds to 0 bar positive pressure and
thus to the ambient pressure (atmospheric pressure).
Pressure In Refrigerant Circuit Lower Than Indicated In Table
Not enough refrigerant in refrigerant circuit
Determine refrigerant circuit leaks. Refer to
⇒ “4.2.1 Refrigerant Circuit, Determining Leaks “, page 143 .
Check pressure relief valve.
If pressure relief valve has responded:
Check coolant fan activation.
Check refrigerant pipes and hoses for cross-section constric‐
tions caused by inadequate bending radii.
Check refrigerant pipes and hoses for external damage.
If no fault is found, clean refrigerant circuit (flush using refrig‐
erant R134a, refer to
⇒ “1.4.13 Refrigerant Circuit Flushing With Refrigerant
R134a“, page 32 or blow through using compressed air and
nitrogen, refer to
⇒ “1.4.12 Refrigerant Circuit Flushing With Compressed Air
and Nitrogen “, page 29 ).
Pressure In Refrigerant Circuit In Line With Table Or Higher
Start the engine.
Set air conditioning system to maximum cooling output.
Note
If the vehicle has a Compressor regulator valve -N280- control
current can be read out in measured value block using Vehicle
Diagnosis, Testing & Information System -VAS5051B- (“OBD“ or
“Guided Fault Finding for the A/C System“) and ⇒ Heating, Ven‐
tilation and Air Conditioning; Rep. Gr. 87 ; Diagnosis and Testing
(vehicle-specific repair manual).
If compressor is not driven with engine running or regulating valve
is not actuated:
Audi 100 1991 ➤ , Audi 80 1992 ➤ , Audi A1 2011 ➤ , Audi A2 2001 ➤ , A ...
Refrigerant R134a Servicing - Edition 01.2011
4. Diagnosis and Testing 157
