Audi A2 2001 - Page 186

Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not
permitted unless authorised by AUDI AG. AUDI AG does not guarantee or accept any liability
with respect to the correctness of information in this document. Copyright by AUDI AG.
Possible deviation from speci‐
fication
Possible cause of fault Corrective action
• High pressure remains con‐
stant or increases only
slightly (above pressure
with engine stopped),
• Low pressure quickly drops
to value in graph or below
• Required cooling output is
not attained
♦ Actuation of A/C compressor regulator
valve -N280- malfunctioning
♦ Not enough refrigerant in refrigerant
circuit
♦ Expansion valve malfunctioning
– Check A/C compressor reg‐
ulator valve activation.
– Extract refrigerant from re‐
frigerant circuit
• If quantity of refrigerant ex‐
tracted is substantially less
than specified capacity:
• High pressure normal
• Low pressure in line with
value in graph
• Required cooling output is
not attained
– Localize leak with leak de‐
tector and eliminate
– Charge the refrigerant circuit
– Repeat test
• High pressure normal
• Low pressure too low (see
graph)
• Required cooling output is
not attained
• If quantity of refrigerant ex‐
tracted roughly corresponds
to specified capacity:
– Replace expansion valve
– Charge the refrigerant circuit
– Repeat test
