Audi Q7
Vehicle Required Adapt‐
ers For The Con‐
nectors To A/C
Compressor
Required Adapters For
Connections To Fluid
Reservoir / To Second
Evaporator.
Other
Audi Q7
(4L_)
from MY
06
♦ Vehi‐
cles
with
one
evap‐
ora‐
tor (2
zone
A/C
sys‐
tem)
– Compressor
manufacturer
Denso (block
connections
with radial
sealing)
♦ Low pressure
side Adapter -
VAS
6338/12-
♦ High pres‐
sure side
Adapter -VAS
6338/3-
– No adapter re‐
quired, dryer is re‐
moved from fluid
reservoir on con‐
denser and the
opening is sealed.
Expansion
valve re‐
moved and
Adapter -
VAS
6338/17-
or adapter
-VAS
6338/33-
installed
(depend‐
ing on the
expansion
valve ver‐
sion or a
drilled ex‐
pansion
valve, for
example,
7L0 820
712 A or
7H0 820
679 B or
7L0 820
679 C in‐
stalled, re‐
fer to
⇒
page 34 ).
Refer to
Electronic
Parts Cat‐
alog (ET‐
KA).
♦ Addi‐
tional
on
vehi‐
cles
with
2
evap‐
ora‐
tors
(4
zone
A/C
sys‐
tem)
To flush circuit with
evaporator in front A/C
unit
♦ Adapter -VAS
6338/5- for sealing
the low-pressure
side connection (to
second evaporator)
♦ Adapter -VAS
6338/11- for seal‐
ing the high-pres‐
sure side connec‐
tion (to second
evaporator)
