PISTONS AND CONNECTING RODS, DISASSEMBLING AND ASSEMBLING
Pistons and connecting rods, disassembling and assembling
Fig. 137: Pistons And Connecting Rods, Disassembling And Assembling Overview
Courtesy of VOLKSWAGEN UNITED STATES, INC.
1 - 30 Nm + 1/4 turn (90 ° ) further
Oil threads and contact surface
To measure radial clearance, tighten to 30 Nm but not further
2 - Pressure relief valve, 27 Nm
2005 Audi A4 Quattro
ENGINE 1.8 Liter 4-Cyl. 5V Turbo Engine Mechanical, Engine Code(s): AMB
