Push valve stem seal onto plastic sleeve.
Carefully press valve stem seal onto valve guide using seal driver 3365.
Remove plastic sleeve.
Fig. 220: Identifying Installation Cartridge VAS 5161/8
Courtesy of VOLKSWAGEN UNITED STATES, INC.
If valve keepers were taken out of cartridge, they must first be placed into insertion device VAS5161/18.
Fig. 221: Identifying Installation Cartridge VAS 5161/8
Courtesy of VOLKSWAGEN UNITED STATES, INC.
Press cartrid
e VAS5161/8 onto insertion device from above and take up valve keepers.
NOTE:
Larger diameter of valve keepers must face upward.
