Fig. 40: Separating Exhaust System At Clamp
Courtesy of VOLKSWAGEN UNITED STATES, INC.
 Separate exhaust system at clamp.
Fig. 41: Removing Bolts Securing Catalytic Converter To Front Exhaust Pipe
Courtesy of VOLKSWAGEN UNITED STATES, INC.
 Remove bolts - arrows - securing catalytic converter to front exhaust pipe.
 Unbolt transmission bracket for exhaust system - arrow -.
NOTE:
 To avoid damage, do not bend decoupling element of front exhaust pipe
by more than 10 °.
