A: Dowel sleeves for centering
13 - ENGINE - CRANKSHAFT, CYLINDER BLOCK
ENGINE, DISASSEMBLING AND ASSEMBLING
Engine, disassembling and assembling
6 M12 x 90 65
7 M10 x 60 45
Component Nm
Bolts/nuts M6 10
M8 20
M10 45
M12 65
except the following:
Engine mount to subframe 25
Engine support to engine mount 25
Drive plate to
Torque converter M10 x1 85
Catalytic converter to turbocharger 30
Brackets for ATF lines 10
Power steering pump to bracket 25
Pulley to power steering pump 25
Pulley to coolant pump 25
Viscous fan to bearing 45
Air conditioning compressor to bracket 25
Component Nm
Drain plug to coolant pump 30
Torque reaction support stop to torque reaction support bracket 28
Hose clamps for coolant hoses 2
Hose clamps for air hoses 3.5
CAUTION: Before beginning repairs on the electrical system:
Obtain the anti-theft radio security code.
Switch the ignition off.
Disconnect the battery Ground (GND) strap.
2005 Audi A4 Quattro
ENGINE 1.8 Liter 4-Cyl. 5V Turbo Engine Mechanical, Engine Code(s): AMB
1:00:56 AM Page 33
