Install in reverse order.
Install ribbed belt.
On completion of work, always:
Start engine and check belt running.
Fig. 70: Correctly Installed Belt
Courtesy of VOLKSWAGEN UNITED STATES, INC.
Correctly installed belt
Bracket for generator, power steering pump and air conditioning compressor, removing and installing
Removing
Lock carrier in service position --> Lock carrier, moving to service position.
Removing ribbed belt --> Ribbed belt, removing and installing.
Draining cooling system --> Cooling system, draining and filling.
Obtain and record radio anti-theft code for vehicles with a coded radio.
NOTE:
Before installing the ribbed belt, make sure that all mechanical units
(generator, air conditioning compressor, power steering pump) are
securely attached.
When installing the ribbed belt, make sure that the direction of rotation is
correct and that the belt is installed correctly in the pulleys.
On vehicles with an air conditioner, install the ribbed belt to the air
conditioning compressor last.
If the vibration damper/pulley is replaced, refer to Installing vibration
damper/pulley.
