Fig. 125: Crankshaft, Removing And Installing Overview
Courtesy of VOLKSWAGEN UNITED STATES, INC.
1 - Bearing shells 1, 2, 4 and 5
 For bearing cap without oil groove
 For cylinder block with oil groove
 Do not interchange used bearing shells (mark)
2 - 65 Nm + 1/4 turn (90 ° ) further
 Replace
 When measuring radial clearance of crankshaft, tighten to 65 Nm but do not turn further
3 - Bearing caps
