Audio Precision AP 52 B Series User Manual

Characteristic Specifications Supplemental Information
60 APx DSIO Module for B Series: Specifications
DSIO
Functional characteristics
Channels
1 data line, TDM 1, 2, 4, 6, 8 or 16 Time division multiplexing (TDM)
Multiple data lines 1, 2, 4, 6 or 8 up to 4 data lines; 2 channels on each
line by TDM
Data formats
I
2
S, DSP, custom (left/right justified,
one bit/one subframe/50% duty cycle
frame, inverted or normal frame,
optionally 1-bit left-shifted frame). All
modes LSB or MSB first
Word width
8–128 bits cannot be less than bit depth
Bit depth (data length)
8–32 bits
Sample rate (frame rate)
4 kS/s–432 kS/s
1, 2, 4, 6 or 8 channels
2
4 kS/s–216 kS/s
16 channels
2
Master Clock range
4 kHz–56 MHz Actual clock rate is dependent upon bit
clock, word width, and sample rate set-
tings.
Logic voltage levels
1.8 V, 2.5 V, 3.3 V
