Characteristic Specifications Supplemental Information
36 APx515 B Series Audio Analyzer: Specifications
GENERAL/ENVIRONMENTAL
Power Requirements
100, 120, 230 or 240 Vac, 50–60 Hz,
with safety ground via approved
power cord, 75 VA max.
Typical operating range is 90–110 Vac
(100V), 108–132 Vac (120V), 198–242
Vac (230V), or 216–264 Vac (240V).
Temperature Range
Operating 0° C to +45° C
Storage –40° C to +75° C
Humidity
10 % to 80 %, non-condensing
Max Operating Altitude
3,000 m [9,840 feet]
Stabilization Time
20 minutes Allow up to 1 hour per 10°C if unit has
been exposed to a significant change
in temperature. Allow 24–48 hours to
recover if condensation has occurred.
EMC
Complies with Directive 2004/108/EC,
IEC 61326-1:2005, EN 61326-1:2006.
Radiated and conducted emissions
are within Class B limits of CISPR 11.
Emission and immunity levels are influ-
enced by the shielding performance of
interface and signal cables attached to
the instrument. EMC compliance was
demonstrated using Audio Precision
cables
Safety
Complies with Directive 2006/95/EC,
IEC 61010-1:2001, EN 61010-1:2001,
CAN/CSA-C22.2 No. 61010-1-04, and
UL Std No. 61010-1 (2nd Edition).
Equipment Class I,
Installation Category II,
Pollution Degree 2,
Measurement Category I
Dimensions (W x H x D)
370 x 86 x 343 mm
[14.55 x 3.40 x 13.53 in]
2U rack mount tray available. D is
351 mm [13.56 in] if rear panel option
keys are installed
Weight
4.45 kg [9.8 lbs]
