Characteristic Specifications Supplemental Information
APx HDMI+ARC I/O Module for B Series: Specifications 67
HDMI
Measurement Range 0 to 20%
Accuracy ±0.5 dB
Residual IMD
1, 3
SMPTE & MOD Typically < –140 dBFS
DFD Typically < –150 dBFS
Frequency Measurement
Range < 5 Hz to 0.499 • SR
Accuracy ±(0.0003% + 100 µHz)
Resolution 6 digits
Phase Measurement
Ranges –90 to +270, ±180, or 0 to 360 deg
Accuracy
1
Typically < 0.001 deg
Resolution 0.001 deg
Notes to Specifications
1. System specification including contributions from both generator and analyzer. Generator-only and analyzer-only
contributions are typically less.
2. Sample rate (SR) must be 27 kHz for specified performance. Jitter analyzer set for 700 Hz highpass response
per AES3-1992.
3. Digital generator word width must be set to 24 bits for specified performance; shorter word widths may degrade
performance.
4. DSP warping may significantly increase roll-off rate and lower ENBW.
