Audio Precision APx555 User Manual

84 APx PDM I/O Module for B Series: Specifications
PDM
Timing Characteristics
PDM TRANSMITTER
t
CLKTX
Clock period (master or slave
mode)
41 7813 ns
t
H
Data hold time
20 ns
t
SU
Data setup time
t
CLKTX
/ 2-30
ns
Logic Level = 0.8 V
t
CO
Clock to out
58 ns
t
R
Rise Time
18 ns
t
F
Fall Time
16 ns
r
OUT
Output Impedance
450 ohms
f
CLK
max
Maximum Clock Frequency
3.072 MHz
Logic Level = 1.0 V
t
CO
Clock to out
32 ns
t
R
Rise Time
10 ns
t
F
Fall Time
7.7 ns
r
OUT
Output Impedance
225 ohms
f
CLK
max
Maximum Clock Frequency
6.144 MHz
Logic Level = 1.5 V
t
CO
Clock to out
18 ns
t
R
Rise Time
5.2 ns
t
F
Fall Time
3.8 ns
r
OUT
Output Impedance
85 ohms
f
CLK
max
Maximum Clock Frequency
12.28 MHz
Parameter Symbol Test Conditions Min Typ Max Unit
