Audio Precision B Series User Manual

76 APx PDM 16 Input Module for B Series: Specifications
PDM 16
INPUT CHARACTERISTICS
Impedance
>100
< 10
kOhms
pf
Input Voltage Range 0 5 V
Interface Voltage (Logic Level) VINT 0.8 3.30 V
Resolution 0.01 V
Accuracy ±0.05 V
OUTPUT CHARACTERISTICS
Output Voltage High VOH ILOAD = 0.5 mA 0.7 × VINT V
Output Voltage Low VOL ILOAD = 0.5 mA 0.3 × VINT V
Output Impedance Zo At connector pin 50 Ohms
VDD OUTPUT
DC Voltage VDD 0.0 3.60 V
Resolution 0.01 V
Accuracy ±0.05 V
Maximum Current IMAX 50 mA
TIMING CHARACTERISTICS
PDM RECEIVER
t
CLKRX
Clock period (master or slave mode) 41 7813 ns
t
HP
Data hold time, rising edge 0 ns
t
HN
Data hold time, falling edge 0 ns
t
SU
Data setup time 9 ns
Parameter Symbol Test Conditions Min Type Max Unit

Audio Precision B Series Specifications

General

Brand	Audio Precision
Model	B Series
Category	Measuring Instruments
Language	English
