APx PDM I/O Module for B Series: Specifications 85
PDM
Logic Level  2.0 V
t
CO
Clock to out
15 ns
t
R
Rise Time
3.9 ns
t
F
Fall Time
2.9 ns
r
OUT
Output Impedance
40 ohms
f
CLK
max
Maximum Clock Frequency
24.576 MHz
PDM RECEIVER
t
CLKRX
Clock period (master or slave
mode)
41 7813 ns
t
HP
Data hold time, rising edge 5 ns
t
HN
Data hold time, falling edge 5 ns
t
SU
Data setup time 5 ns
Parameter Symbol Test Conditions Min Typ Max Unit
t
SU
t
SU
t
HP
t
SU
t
HN
t
CLK
t
H
t
H
t
SU
BITCLK
DATA TX CH 1
CH 1
CH 2
CH 2
DATA RX
