CONTROLS AND INDICATORS
1) Volume control - Line in input
2) Master volume control
3) Mains switch
7) Speaker Level input (from
amplifier)
8) Mains cord ( 115V )
WARNING !
To reduce the risk of electric shock, do not open or remove cover or back. Do not expose this appliance to rain or moisture. In case of malfunction consult qualified service personel.
The exclamation point, within an equilateral triangle, is intended to alert the user of the presence of
important operating and maintenance (servicing) instructions in the literature accompanying the appliance.
The lightning flash with arrowhead, within an equilateral triangle, is intended to
alert the user of the presence of uninsulated "dangerous voltage" within the product´s
enclosure; that may be of sufficient magnitude to constitute a risk of electric shock to
persons.
4) Fuse ( T2AL 250V for 115V )
5) Standby mode switch
6) Low level input (MONO) from
amplifier (Subwoofer out)
Note regarding Line in input:
Line-in shall only be connected
when the speaker is used in a 5.1
Home Theater system.
1
2
5
6
7
3
4
8
