Audio Research Reference 3 - Unit Layout and Controls; Front Panel Overview; Rear Panel Connectors

Model Reference 3
VACUUM TUBE PRE AMPLIFIER RE F E RE N CE 3 HIGH DEFI NITION
®
POWER PROC BAL/SE MUTE
VOLUME SELECT INPUT
D I S P L A Y
MODEL REF 3
STEREO PREAMPLIFIER
WARNING
TO PREVENT FIRE AND SHOCK HAZARD,
DO NOT EXPOSE THIS DEVICE TO RAIN
OR MOISTURE.
PLYMOUTH, MINNESOTA
MADE IN U.S.A.
SERIAL
VOLTS
3A FUSE SLO-BLO
T2A (230V)
200 WATTS MAX
50/60 HZ
˜
+12V
C D
C D
TUNER
TUNER
R I G H T
R I G H T
R I G H T
R I G H T
PHONO
PHONO
VIDEO
VIDEO
AUX 1
AUX 1
VAUX 2
VAUX 2
PROCESSOR
PROCESSOR
RECORD OUT
RECORD OUT
MAIN OUTPUTS
MAIN OUTPUTS
UNIT MUST BE OPERATED
IN A HORIZONTAL POSITION.
- DO NOT OPERATE WITH COVERS REMOVED-
UNIT CONTAINS VOLTAGES
WHICH MAY BE HAZARDOUS.
