5
Part names and functions
■ Accessories
• Cable 1.2 m (3.9’) / 3.5 mm (1/8“)
gold-plated stereo mini-plug/L-type
• USB charging cable
(30 cm (1') long)
L/R (left/right)
indicator
Multi-indicator lamp
Volume buttons
Microphone
(for calls)
Multifunction button
Noise-cancelling
indicator lamp
Connector jack
Displays the operating status and battery
level of the product.
Use to play or pause music, and
operate calls.
Adjust the volume using + and –.
Displays the operating status
of the noise-cancelling function.
Use to connect the included cable for
wired connections (playthrough function).
Power switch
Turns the power
on and off.
Headband
Earpad
Housing
Joint
Arm
Slider
Microphone
(for noise cancelling)
Battery jack
Use to connect the included USB
charging cable and charge the product.
Headpad
