4
Part names and functions
Housing
Eartips
Bushing
LEFT/RIGHT
(L/R) indicator
The left bushing has a
protruding part.
■ Headphones
■
Bluetooth
®
and NFC
transmitter/receiver
N-Mark
Battery jack
Shows the
location for
detecting NFC.
Connect the included USB
charging cable to charge.
■ Remote control with mic
Microphone
Indicator lamp
Displays the operating
status of the product.
Use to make a phone call.
Power switch
Turns the power on/off.
Control button
Volume button (+)
Use to play/pause music
and videos and answer/end
phone calls.
Use to turn the volume up.
Volume button (−)
Use to turn the volume down.
ATH-CKS550BT_UM_V2_6L_book.indb 4 2017/01/23 10:03
