■ Pairing
1. Starting with the product turned off, slide the power switch to the “ON” position.
2. Insert the transceiver to your PC.
3. After pairing is complete, the indicator lamp of the headphones and transceiver light in
blue.
■ Wearing the product
Place the side of the product marked “L” (LEFT) over the left ear and the side marked “R”
(RIGHT) over the right ear, slide the slider up or down so that the earpads cover your ears, and
then adjust the headband.
■ Swivel mechanism
You can fold the housing so that it lies flat.
ONON
■ Charging
• Fully charge the battery when using for the first time.
• When the rechargeable battery is running low, the product will make a sound through the
headphones, and the multi-indicator lamp will flash in red. In this case, charge the battery.
■ Specifications
•
Headphones
Type Closed-back dynamic
Driver 45 mm
Sensitivity 101 dB/mW
Frequency response 5 to 40,000 Hz
Impedance 45 ohms
Power supply DC 3.8 V lithium polymer battery
Weight 290 g (without mic)
•
Microphone
Type Electret condenser
Polar pattern Unidirectional
Sensitivity -43 dB (1V/Pa, at 1kHz)
Frequency response 30 to 20,000 Hz
•
Transceiver
RF output 12. 5 mW EIRP
Maximum communication range Line of sight - approx. 12 m
Frequency band 2.404 GHz to 2.476 GHz
Modulation method AFH
Transmission band 20 to 24 kHz (24,000 Hz)
Power supply DC 5 V (USB BUS POWER)
Dimensions 50×15×10mm
Weight 9 g
•
Other
Charging time Approx. 7 hours*
Operating time Continuous transmission time: Max. approx. 15 hours
Operating temperature 5°C to 40°C (41°F to 104°F)
Accessories USB charging cable (2 m), Windscreen, Spare Earpad,
Detachable Microphone
* The figures above depend on operating conditions.
For product improvement, the product is subject to modification without notice.
While charging, the multi-indicator lamp lights as follows (it may take several seconds for the
multi-indicator lamp to light).
Flashing in blue
Flashing in blue
Blue
Blue
Red
Off
