Audio Technica BPHS1 User Manual

BPHS1
Specications
LEGEND
200 Hz
1 kHz
5 kHz
8 kHz
SCALE IS 5 DECIBELS PER DIVISION
240˚
180˚
210˚
270˚
300˚
330˚
0˚
150˚
120˚
90˚
30˚
60˚
1
/ 4 " Close Talking
Frequency in Hertz
Response in dB
10 dB
100
50
200
10k
5k
1k
500
2k
20k
Tested using Brüel & Kjaer Type 4227 Artificial Mouth
LEGEND
200 Hz
1 kHz
5 kHz
8 kHz
SCALE IS 5 DECIBELS PER DIVISION
240˚
180˚
210˚
270˚
300˚
330˚
0˚
150˚
120˚
90˚
30˚
60˚
1
/ 4 " Close Talking
Frequency in Hertz
Response in dB
10 dB
100
50
200
10k
5k
1k
500
2k
20k
Tested using Brüel & Kjaer Type 4227 Artificial Mouth
microphone
frequency response: 40–20,000 Hz
microphone
polar pattern
Closed-back dynamic
40 mm, neodymium magnet, copper-clad
aluminum wire voice coil
Dynamic
Cardioid
Headphone: 20-20,000 Hz
Microphone: 40-20,000 Hz
–57 dB (1.4 mV) re 1V at 1 Pa (microphone)
100 dB (headphone)
1,600 mW at 1 kHz
Headphone: 65 ohms
Microphone: 560 ohms
264 g (9.3 oz)
82.0 mm (3.23") wide (earcup); 46.0
mm (1.81") wide (headband); 180.1
mm (7.09") long (boom), microphone
extended; 24.0 mm (0.94") diameter
(microphone)
3.3 m (10.8') long with 8-pin connector at
headset end; 3-pin XLRM-type connector
(microphone) and 6.3 mm (
1
/
4
") phone
plug (headphone) outputs
3 windscreens; spare connector screw
Headphone type
Headphone driver
Microphone element
Microphone polar pattern
Frequency response
Open circuit sensitivity
Sensitivity
Maximum input power
Impedance
Weight
Dimensions
Cable
Accessories furnished
In the interest of standards development, A.T.U.S.
offers full details on its test methods to other industry
professionals on request.
1 Pascal = 10 dynes/cm
2
= 10 microbars = 94 dB SPL
1
Typical, A-weighted, using Audio Precision System One.
Specications are subject to change without notice.
XLRM-TYPE
1
/4
||
PLUG
FUNCTION END “A” END “B” END “C”
SHIELD PINS 3–6 PIN 1 PIN 1
MIC AUDIO (–) PIN 2 PIN 3 –
MIC AUDIO (+) PIN 1 PIN 2 –
SPEAKER AUDIO (R) PIN 7 – PIN 2
SPEAKER AUDIO (L) PIN 8 – PIN 3
Audio-Technica U.S., Inc., 1221 Commerce Drive, Stow, Ohio 44224
Audio-Technica Limited, Old Lane, Leeds LS11 8AG England
©2010 Audio-Technica U.S., Inc. audio-technica.com P52117-01

Audio Technica BPHS1 Specifications

General

Headset type	Binaural
Product type	Headset
Plug and Play	Yes
Product color	Black
Wearing style	Head-band
Recommended usage	-
Connectivity technology	Wired
Impedance	65 Ω
Driver unit	40 mm
Magnet type	Neodymium
Ear coupling	Circumaural
Headphone frequency	20 - 20000 Hz
Headphone sensitivity	100 dB
Microphone frequency	40 - 20000 Hz
Microphone sensitivity	-57 dB
Microphone connectivity	6.3 mm
Microphone input impedance	560 Ω
Quantity	1
