Diffusori attivi - Active Speakers
Diffusori attivi - Active Speakers
6
Precautions:
Caution: When using any electric product , precautions should always be taken, including the following:
1) Read carefully all instructions before using the product.
2) To reduce the risk, strict supervision is necessary when the product is used near children.
3) Don't use the product near to water sources like sinks, kitchens, wet floors, pools,
or similar or when raining.
4) In case hearing losses or buzzing occur, please contact a doctor.
5) This products should be located so that its position does not interfere or reduce its proper ventilation.
6) This product should be site away from heat sources such as radiators or any other product that
generate heat.
7) This product should be connected to a power supply line only of the type described on the operating
instructions. Check always the status of the power cable.
8) In case you need to replace the fuse, unplug power supply before replacement. The fuse is located
over the power socket and needs to be replaced with a fuse of same type and value. If the fuse blows again,
please contact our service. DON'T replace it a second time with a higher value fuse.
9) Unplug power supply when left unused for a long period of time. Don't draw the cable but pull out the
plug.
10) Make sure that power switch can always be easily reached.
11) The product needs to be inspected by authorized or qualified personnel in case:
A- The power cable or plug are damaged
B- Objects or liquids fall inside the product
C- The product has been exposed to rain
D- The product doesn't appear to operate normally or exhibits a marked change in performance.
E- The product has fallen and been damaged.
12) DON'T operate on the product, except indications on the user's manual . Please refer to authorized
and qualified personnel for any other operation.
13) Caution: Don't place objects on the product's power cable or place it in a position where it could be
damaged or cause interferences. Improper installation could cause fire risk and/or personal injury.
Service
All Audio Design PRO products have been inspected and tested before leaving the factory and , if properly
used, they will work for many years. However, in case of any problem, please proceed in the following way:
Contact your dealer and inform about the defect you found
In case it won't be possible to solve the problem with the dealer, the product needs to be returned, preferably
in its original packaging or in a proper packing to protect it during the transport. Purchase documents must
be produced too.
Your dealer will arrange the shipment to our service centre.
CE Conformity:
Audiodesign Pro products comply with presently existing directives and standards.
Introduction
Thank you for purchasing an AudioDesign Live Pro active speaker.
Live Pro series are designed to provide extremely high SPL and stunning sonic performance.
Main features are:
* A/B Class separate amplifer for woofer and tweeter for items PAX 2 12 and PAX 2 15
* High SPL
PAX 2 10 B,
* A/B Class amplifer for items PAX 2 8 and PAX 2 12 USB
Serie PAX2
Serie PAX2
Specification PAX2 15 PAX2 12 PAX2 12 USB PAX2 10 B PAX2 8
Max Power W 450 400 360 320 160
Rated Total Power W 250 220 200 180 100
Low Frequencies Rated Power W 200 180 140
High Frequencies Rated Power W 50 40 40
Distortion at Rated Power < 1% 1% 1% 1% 1%
Max SPL dB 126 124 123 120 115
Frequency response Hz 55÷20.000 55÷20.000 55÷20.000 60÷19.000 60÷18.000
Hori zontal Dispersion angle ° 90 90 90 90 90
Vertical Dispersion angle ° 60 60 60 60 60
Woofer si ze mm 380 320 320 250 200
Woofer V/C mm 75 65 65 50 38
Compressor driver V/C mm 43 34 34 34 34
Mic 1 Input Jack + XLR Jack + XLR Jack + XLR Jack + XLR Jack + XLR
Mic 2 Input Jack + XLR --- --- --- ---
USB Input con Display
Line Input RCA + XLR RCA + XLR RCA + XLR RCA + XLR RCA + XLR
Output Jack + XLR Jack + XLR Jack + XLR Jack + XLR Jack
Mic Level Control Yes (2) Yes Yes Yes Yes
Line Level Control Yes Yes Yes Yes Yes
USB Level Control --- --- Si --- ---
Main Level Control Yes Yes Yes Yes ---
Bass & High Tone control Yes Yes Yes Yes Yes
Dimensions (WxLxH) cm 46x40x69 43x32x59 43x32x59 36x28x51 30x25x42
Weight Kg 22,5 17,3 18,3 12 8,6
