FR-X user’s manual
3
1. Securing cabinets with the H prole to ensure perfect coupling
a) Put the cabinets side by side and line up the cargo points
b) Sliding of the H prole to make the coupling:
The AUDIOFOCUS H prole ts the cabinet cargo hardware perfectly to join cabinets
c) Slide the two H proles in the top and bottom cargo proles
