AUDIOFOCUS FR-X SYSTEM - System Configuration Examples

FR-X user’s manual
4
d) Once the H proles are fully inserted (1), connect the front and rear M10 shackles to lift the complete set (2)
Examples of congurations
FR-X vertical coupling
2 x FR-X on truss (cargo)
FR-X horizontal coupling FR-X pole mounted
1 2
