4.Connections
Analogue Inputs(Line)
Connect your analogue sources to one of the three line-level inputs, AUX1, AUX2 or AUX3.
Phono Input(MM)
Connect your turntable (moving magnet cartridge) to the phono input. Connect the earth lead from your turntable (if available) to the ground terminal.
Coaxial Digital Input
Connect your coaxial digital sources to either COAX1 or COAX2.
Optical Digital Input
Connect your optical digital sources to either OPT1 or OPT2.
Pre-Amplifier Output
Pre-amplifier output for driving external power amplifiers, subwoofers or signal processors.
Loudspeaker Terminals
One set of loudspeaker output terminals.
Headphone Output
A stereo 6.3mm (1/4”) jack is provided on the front panel for connecting headphones. When headphones are connected the audio to the loudspeakers terminals will be
cut off.
Bluetooth Connection
Select BT source on the 7000A, on your mobile device search for 'audiolab 7000A-xxxx' and connect.
Once paired, the Bluetooth icon will appear on the 7000A display. If you switch to another input on the 7000A your mobile device will be disconnected after 60 seconds.
To reconnect, select BT on the 7000A and it will connect to the last paired device, or select ' audiolab 7000A-xxxx ' on your mobile device in the Bluetooth menu and it
will reconnect.
USB Update
Put the update file into the USB drive, plug in the UPDATE USB interface, press the STANDBY button on the front panel then POWER ON, your 7000A will upgrade
automatically. After the completion, unplug the USB drive and restart 7000A, now it can be used.
