Audiolab 7000A User Manual

MODE
POWER AMP IN
PRE OUT
HEADPHONE OUT
LOUDSPEAKERS
PRE
DISABLE
ACTIVE
ACTIVE
DISABLE
PRE POWER
ACTIVE
ACTIVE
ACTIVE
ACTIVE
INTEGRATED
DISABLE
ACTIVE
ACTIVE
ACTIVE
Integrated Mode
The pre-amplifier section is internally connected to the power amplifier, pre-amplifier output is also operational in this mode. A second power amplifier can be connected for
bi-amplification as shown in the diagram.
下图仅供参考，详情按
Omnia
修改
Pre-power Mode
The pre-amplifier section is internally disconnected from the power amplifier. The 7000A can be used as a stand alone power amplifier (ie. part of an AV setup). This mode can also be
used if additional signal processing is required, connecting the pre-out to an external signal processor and then take the output from the processor to the 7000A Power-IN.
参考
Omnia
修改
Pre-Mode
All signals to and from the power amplifier of the 7000A are disconnected. In this mode, the 7000A functions as a stand-alone pre-amplifier. The pre- amplifier section of the 7000A
can be connected to a stereo power amplifier, or to two mono-block amplifiers.
图参考
Omnia
修改

Audiolab 7000A Specifications

General

Type	Integrated Amplifier
Signal to Noise Ratio	> 110dB (A-weighted)
Weight	8.4 kg
Frequency Response	20Hz - 20kHz (±0.5dB)
Inputs	1 x Coaxial, 1 x USB, 1 x Optical
Outputs	1 x Headphone, 1 x Pre-Out
Bluetooth	Yes (aptX/aptX HD)
