Audiolab 7000A - Power Amplifier and Headphone Specs

4.5mV (Phone MM, Volume=0dB)
Input Impedance
10K(Line)
47K // 100pF(Phono MM)
Total Harmonic Distortion (THD)
< 0.0005% (1KHz @ 2V, Volume = 0dB)
Frequency response
20Hz-20kHz (+/-0.1dB)
Output voltage
2.3V max. (Volume = 0dB)
Output impedance
100 ohm
Signal-to-Noise ratio
> 110dB (Line,A-weighted)
> 76dB (Phono MM,A-weighted)
DAC
D to A Converter
ES9038Q2M
Total Harmonic Distortion (THD)
< 0.0006% (1KHz @ 0dBFS)
Output level (0dBFS, 1KHz)
2.05Vrms
Max. Sampling Frequency
Optical,Coaxial:192KHz
Ethernet,WiFi:192KHz
USB A：48kHz
PC USB :PCM768kHz,DSD512
Signal-to-noise ratio (S/N)
> 112dB (A-weighted)
Power Amplifier Section
Gain
+29dB
Rated Power Output
2 x 70W (8 ohm, THD<1%)
2 x110W (4 ohm, THD<1%)
Frequency Response
20Hz-20kHz (+/-0.3dB)
Total Harmonic Distortion (THD)
<0.003% (1kHz @ 50W/8ohm)
Input Sensitivity
720mv
