AudioSource SW 50 - Television Enhancement

Television Enhancement
Many newer television sets are equipped with variable stereo outputs. The signal available at these
outputs varies with the television volume. In this situation, these variable audio outputs can be connected
directly to the SW 50 line inputs to enhance the bass response of the television's built-in speakers.
