36
•Pickup Truck:
1. Use a blunt plastic putty knife or similar blunt tool to lift the rubber
molding around the windshield and tuck the antenna cable underneath it.
2. Continue tucking the cable underneath the windshield molding around
the windshield to the lowest corner.
3. At the lowest corner of the windshield, route the cable out of the
windshield molding and into the rubber weather stripping around the
door opening. Lift the weather stripping from the opening and tuck
the cable inside it, then replace the weather stripping. Run the cable
inside of the weather stripping to the bottom of the door opening.
4. Pull the cable out of the weather stripping at the bottom of the door
opening and route it under the carpet toward the dashboard. Coil any
excess cable in a hidden location, such as under the carpet, keeping
it away from any vehicle pedals or controls. Secure the excess cable
with wire ties.
5. Bring the end of the cable out at the
PowerConnect Vehicle Dock location.
Leave yourself enough cable so you
can easily connect it to the antenna
connector of the dock.
6. Continue with “Step 5: Connect
the Magnetic Mount Antenna and
PowerConnect Power Adapter” on
page 37.
Vehicle Installation
To Next Page
