Audison LR 132 - Amplifier Block Diagram; Amplifier Internal Structure; TRI-MODE Connection Details; Loudspeaker Impedance Chart

7
18
BLOCK DIAGRAM
21.0
15.9
12.7
10.6
8.5
6.4
330
245
200
165
132
100
L (mH)
C (µF)
8 Ohms
LOUDSPEAKERS IMPEDANCE
TRI - MODE CONNECTION
TRI MODE SYSTEM WITH FADER
C (µF)
660
495
400
330
265
200
4 Ohms
10.6
7.9
6.4
5.3
4.3
3.2
L (mH)
60
80
100
120
150
200
FREQUENCY
Hertz
HI-PASS
HI-PASS
SUBWOOFER
